• Wide range of measurement and control, 1-1,000mbar
• Two control modes available Single-point control and programmed control
•Stores up to 5 programs, each containing up to 5 steps of programming control
•Large TFT touch screen display control provides easy operation
•All parts in contact with vapor or liquid are made of PTFE, ceramics or other high-performance materials which effectively resists corrosion caused by organic solvents, water, acid and alkali
•Built-in vent valve can feed inert gas into system equipment •One-click decompression allows easy installation and dismantling of vacuum system
| Cat.No. |
6031100300 |
Vacuum setting range |
1-1000mbar |
|
Control mode
|
Single-point control mode, Programmed control mode |
Control program |
Can store up to 5 programs, each containing 5-step control (capable to set the degree of vacuum and time)
|
| Setting method |
Touch screen setting |
Display |
5‘’TFT |
| Sensor overload pressure |
1,500mbar |
Compatible conditions |
Power of 50Hz vacuum pump ≤400W；Power of 60Hz vacuum pump ≤500W |
| Connector diameter |
8mm |
Materials in contact |
PTFE, PP, silicone and ceramics |
| Power |
600W |
Voltage,Frequency
|
110-240V,50/60Hz |
| Overall dimensions [WxDxH] |
189x207x193mm |
Weight
|
4.0kg |
| Ambient temperature |
10-40℃
|
Permissible ambient humidity
|
≤80% RH
|
