Optical System
|
Single Beam
|
Light Source
|
Tungsten Lamp(Japan HYBEC) | Deuterium Lamp(Milaras)
|
Spectral Bandwidth
|
2.0nm
|
Wavelength Range
|
190-1100nm
|
Wavelength Accuracy
|
±0.5nm
|
Wavelength Repeatability
|
≤0.3nm
|
Photometric Range
|
-0.3 - 3.0 A, 0 - 200%T
|
Photometric Accuracy
|
±0.002 A @ 0.5 A, ±0.004 A @ 1.0 A, ±0.3%T @ 100%T
|
Photometric Repeatability
|
≤0.001 A @ 0.5 A, ≤0.002 A @ 1.0 A, ≤0.15%T @ 100%T
|
Stability
|
≤0.002 A/h @ 500 nm ( after preheat 2 hours)
|
Stray Light
|
≤0.05%T @ 220 & 360nm
|
Sample Compartment
|
4-position, 10mm pathlength cuvette
|
Display
|
Dot Matrix LCD
|
Output
|
USB Port & Parallel Port ( Printer)
|
Power Requirements
|
110/220VAC, 50/60Hz, 120W
|
|
Dimension[L×W×H]
|
475×360×225mm
|
|
Weight
|
14.6kg
|
