| Evaporating flask volume |
50-3000mL
|
| Temperature range |
Room temp.-180°C
|
Temperature control accuracy
|
water: ± 1°C ；oil: ±3°C
|
Speed range
|
20-280rpm
|
Direction of Rotation
|
Clockwise and counterclockwise
|
Evaporation capacity
|
Max.1.56L/h（H20）
|
Temperature control
|
Micro processer PID control
|
Display
|
LCD
|
Timer
|
Yes |
Time Setting Range
|
1-999min |
Lifting mode
|
Motorized |
Lifting stroke
|
150mm
|
Motor Type
|
Brushless DC motor
|
Heating Power
|
1300W
|
Power
|
1400W
|
Voltage/Frequency
|
100-120/200-240V，50/60Hz
|
Dimension[D×W×H]
|
465×457×583mm
|
Weight
|
15kg |
Permissible ambient temperature
|
5-40°C
|
Permissible ambient humidity
|
≤80% RH
|
Protection Class
|
IP20
|
USB Interface
|
Yes |
Safety features
|
Motor over-current protection, earth-leakage protection lifting overload protection, Boil-dry protection, Overheating protection
|
Applications
|
Chemical research, pharmaceutical manufacturing, food processing, cosmetics manufacturing, and chemical laboratories.
|
