• Brushless DC motor is maintenance free and explosion-proof
• Digital temperature control with max. temperature at 340°C • Digital speed control with max. speed up to 1500rpm
• Max. stirring quantity of H2O at 20L
• Safety circuits provide overheating protection
• The “HOT” warning will flash if the plate temperature is above 50°C even when the hotplate is turned off
• Wide range timer function from 1min to 99h59min
| Cat.No. |
8030201110 |
Work plate Dimension |
Ø135mm（5 inch） |
|
Work plate material
|
stainless steel cover with ceramic coating |
Max. stirring quantity [H2O] |
20L |
| Speed range |
100-1500rpm resolution ±1rpm |
Speed display |
LCD |
| Temperature display |
LCD |
Heating temperature range |
Room Temp.-340℃, increment 1℃ |
| Temperature control accuracy |
±1℃(<100℃) ±1%(>100℃) |
Temperature display accuracy |
|
| External temperature sensor |
PT1000 (accuracy ±0.2℃) |
"Hot" warning
|
50℃ |
| Overheating protection |
420℃ |
Motor type
|
Brushless DC motor |
| Stirring positions |
1
|
Max. magnetic bar length
|
80mm
|
| Timer function |
1min-99h59min |
Protection class |
IP21 |
| Motor rating output |
10W |
Power |
550W |
| Heating output |
500W |
Voltage,Frequency |
100-120V/200-240V，50/60Hz |
| Dimension [WxDxH] |
160x280x100mm |
Weight
|
2.8kg |
| Ambient temperature |
5-40℃
|
Permissible ambient humidity
|
80% RH |
| Data connector |
RS232 |
Motor rating input |
18W |
