| Feed Water Requirements |
|
| Tap Water |
Municipal water, Conductivity < 2000 μS/cm (1000 ppm) |
| Operating temperature |
5 – 35 ℃ |
| Feed water pressure |
1 – 6 bar (15 – 90 psi) |
| Water Flow Rate |
|
| EDI water production rate (@ 25℃) |
5, 10, 15 L/hr |
| EDI water dispensing rate |
Up to 2.0 L/min |
| Ultrapure water dispensing rate |
Up to 2.0 L/min |
| Product Water Quality |
|
| RO rejection |
97 to 98% ionic rejection (new RO cartridge)
> 99% organic rejection
> 99% particulates & bacteria rejection |
| EDI water resistivity (@ 25℃) |
> 5 MΩ·cm (typically 10 – 16 MΩ·cm) |
| EDI water TOC* |
< 30 ppb |
| Ultrapure water resistivity (@ 25℃) |
18.2 MΩ·cm |
| Ultrapure water TOC* |
< 2 ppb |
|
Particles in ultrapure water
( > 0.2 μm)
|
No particles (with a 0.2 μm final filter or RephiBio filter) |
| Microorganisms in ultrapure water |
< 0.001 cfu/ml (with a 0.2 μm final filter or RephiBio filter) |
| Pyrogens in ultrapure water |
< 0.001 Eu/ml (with a RephiBio filter) |
| RNase in ultrapure water |
< 0.5 pg/ml (with a RephiBio filter) |
| DNase in ultrapure water |
<10 pg/ml (with a RephiBio filter) |
| Product Water Quality Stored in Tank ( for tank recirculation models ) |
|
| Resistivity (＠25℃) |
> 1 MΩ·cm (default), adjustable |
| Dimensions |
|
|
Main system dimensions
Width × depth × height
|
32 × 44 × 54 cm (12.6 × 17.3 × 21.3 in)
|
|
Dispenser dimensions
Width × depth × height
|
21 × 29 × 61 cm (8.3 × 11.4 × 24.0 in)
|
| Weight |
20 kg |
| Input Voltage |
110 – 240 VAC |
| Operating Voltage |
24 VDC |
